To facilitate quick selection for engineers, this article provides a systematic overview of NIDEC's mainstream stepper linear motor offerings for design reference.
NIDEC's SPS10 and SPS20 series non-captive linear stepper motors are both actuators with a lead screw structure that convert the motor's rotational motion into linear motion of the front shaft.
The ∅6mm planetary gear stepper motor is a systematic engineering project that integrates ultra-precision machining, special material processing, and extreme assembly techniques, and its challenges are inherently systemic.
NIDEC's LPD4R5SG series is a ∅6mm linear stepper motor with a gearbox, delivering a thrust force greater than 3N.
